DESCRIPTION
A performance fit for the global stage and inheriting many features from its big brother, the A-S2200 delivers an authentic, powerful yet somehow elegant and emotional Hi-Fi sound. Absolute musicality from a luxuriously beautiful instrument.
Floating Balanced Circuit for Power Amplifier
Fully-Balanced Transmission From Input To Output
Tone Control Circuit with A Parallel Volume System
Large Power Supply with Four Separate Circuits
Left-Right Symmetrical Design
Fully Discrete Phono Amp
Low-Impedance, High-Performance Headphone Amp
Toroidal Transformer
Toroidal power transformers, renowned for their superior performance in Hi-Fi components has been appointed to power the A-S2200. Its ability to maintain energy when compared to substitutes aids the A-S2200 in delivering all the emotional energy of the artist infused in the music.
Gorgeous Level Meters
The level meters are both a nod to the nostalgic era of Hi-Fi while simultaneously demonstrating the importance of pure Hi-Fi for today’s discerning enthusiast. Visually presenting the dynamics and pulse of the music, the level meters imbue a warm feeling through their softly illuminated LEDs.
Thick Wires for Ground Connection
A naturally open sound stage is achieved through a culmination of design and component selection. Thick wires for ground connection were purposely selected, adding to the overall low impedance amplifier design, producing a wide and open sound stage for the listener. Consequently, the components disappear, leaving the artist in their place.
Original Speaker Terminals
Cut directly from pure brass, the luxurious speaker terminals effortlessly allow tightening by hand, achieving a highly secure connection.
Mechanical Ground Concept
The Mechanical Ground Concept adopted in the A-S2200 maximizes rigidity and reduces any unwanted vibration, achieving expressive and rhythmic bass. Further rigidity is achieved with the large power transformer, block capacitors and heat sink directly bolted to the chassis while the feet, with bolts directly welded to the main chassis, provide further reinforcement for absolute rigidity.
Chrome-Plated Brass Feet
Completing the amplifier rigidity are the heavy-duty chrome-plated brass feet.
SPECIFICATIONS
Rated Output Power [20 Hz-20 kHz, 0.07% THD]: 90 W + 90 W (8 ohms), 150 W + 150 W (4 ohms)
High Dynamic Power/Channel (8/6/4/2 ohms): 105/135/190/220 W
Damping Factor: > 250 (1 kHz, 8 ohms)
Frequency Response: +0 / -3 dB (5 Hz-100 kHz) , 0 / -0.3 dB (20 Hz-20 kHz)
RIAA Equalization Deviation: +/-0.5 dB (PHONO (MM/MC))
Total Harmonic Distortion (20Hz to 20kHz)
PHONO MC - LINE2 OUT: 0.02 % (1.2 Vrms)
PHONO - LINE2 OUT: 0.005 % (1.2 Vrms)
CD, etc./BAL - SP OUT: 0.035 % (50 W/8 ohms)
Signal-to-Noise Ratio
PHONO MC: 90 db
PHONO MM: 96 dB
CD, etc.: 110 dB
BAL: 114 dB
Input Sensitivity: [1 kHz, 100 W/8 ohms]
PHONO MC: 150 uVrms/50 ohms
PHONO MM: 3.5 mVrms/47 kohms
CD, etc.: 200 mVrms/47 kohms
MAIN IN: 1 Vrms/47 kohms
BAL: 200 mVrms/100 kohms
Transformer: 625VA (Toroidal)
Dimensions (W x H x D): 17-1/8" x 6-1/8" x 18-1/4"
Weight: 50.0 lbs.
DESCRIPTION
A performance fit for the global stage and inheriting many features from its big brother, the A-S2200 delivers an authentic, powerful yet somehow elegant and emotional Hi-Fi sound. Absolute musicality from a luxuriously beautiful instrument.
Floating Balanced Circuit for Power Amplifier
Fully-Balanced Transmission From Input To Output
Tone Control Circuit with A Parallel Volume System
Large Power Supply with Four Separate Circuits
Left-Right Symmetrical Design
Fully Discrete Phono Amp
Low-Impedance, High-Performance Headphone Amp
Toroidal Transformer
Toroidal power transformers, renowned for their superior performance in Hi-Fi components has been appointed to power the A-S2200. Its ability to maintain energy when compared to substitutes aids the A-S2200 in delivering all the emotional energy of the artist infused in the music.
Gorgeous Level Meters
The level meters are both a nod to the nostalgic era of Hi-Fi while simultaneously demonstrating the importance of pure Hi-Fi for today’s discerning enthusiast. Visually presenting the dynamics and pulse of the music, the level meters imbue a warm feeling through their softly illuminated LEDs.
Thick Wires for Ground Connection
A naturally open sound stage is achieved through a culmination of design and component selection. Thick wires for ground connection were purposely selected, adding to the overall low impedance amplifier design, producing a wide and open sound stage for the listener. Consequently, the components disappear, leaving the artist in their place.
Original Speaker Terminals
Cut directly from pure brass, the luxurious speaker terminals effortlessly allow tightening by hand, achieving a highly secure connection.
Mechanical Ground Concept
The Mechanical Ground Concept adopted in the A-S2200 maximizes rigidity and reduces any unwanted vibration, achieving expressive and rhythmic bass. Further rigidity is achieved with the large power transformer, block capacitors and heat sink directly bolted to the chassis while the feet, with bolts directly welded to the main chassis, provide further reinforcement for absolute rigidity.
Chrome-Plated Brass Feet
Completing the amplifier rigidity are the heavy-duty chrome-plated brass feet.
SPECIFICATIONS
Rated Output Power [20 Hz-20 kHz, 0.07% THD]: 90 W + 90 W (8 ohms), 150 W + 150 W (4 ohms)
High Dynamic Power/Channel (8/6/4/2 ohms): 105/135/190/220 W
Damping Factor: > 250 (1 kHz, 8 ohms)
Frequency Response: +0 / -3 dB (5 Hz-100 kHz) , 0 / -0.3 dB (20 Hz-20 kHz)
RIAA Equalization Deviation: +/-0.5 dB (PHONO (MM/MC))
Total Harmonic Distortion (20Hz to 20kHz)
PHONO MC - LINE2 OUT: 0.02 % (1.2 Vrms)
PHONO - LINE2 OUT: 0.005 % (1.2 Vrms)
CD, etc./BAL - SP OUT: 0.035 % (50 W/8 ohms)
Signal-to-Noise Ratio
PHONO MC: 90 db
PHONO MM: 96 dB
CD, etc.: 110 dB
BAL: 114 dB
Input Sensitivity: [1 kHz, 100 W/8 ohms]
PHONO MC: 150 uVrms/50 ohms
PHONO MM: 3.5 mVrms/47 kohms
CD, etc.: 200 mVrms/47 kohms
MAIN IN: 1 Vrms/47 kohms
BAL: 200 mVrms/100 kohms
Transformer: 625VA (Toroidal)
Dimensions (W x H x D): 17-1/8" x 6-1/8" x 18-1/4"
