The VRDS-701 CD player employs a newly-developed VRDS mechanism and a TEAC original discrete DAC “TRDD 7”. The VRDS is a TEAC-original CD drive mechanism that reduces rotation vibration and other unwanted vibration by clamping the CD to an aluminum turntable with the same diameter in order to maximize inertial mass.
Furthermore, instead of an ordinary DAC IC for the DAC section, which is crucial to audio quality, the VRDS-701 has a “TRDD 7” discrete DAC that incorporates our unique algorithms in a discrete circuit.
Unconstrained by conventional CD player definitions, the VRDS-701 is enhanced with future-forward functionality. The ability to play MQA CDs using full MQA decoding capabilities and support for 22.5MHz DSD and 384kHz/32-bit PCM formats as a USB DAC are some of the features that make it more than just a CD player.
TEAC VRDS-701 Balanced CD Player, DAC, Preamplifier, & Headphone Amplifier (Silver)
- $3,999.99
- FREE SHIPPING
Dedicated Support from Start to Finish
- Concierge-Level Experience tailored to your needs
- Assistance with Troubleshooting and Product Insights
- Expert help for Product Set-Up
- Free Shipping on all orders
The VRDS-701 CD player employs a newly-developed VRDS mechanism and a TEAC original discrete DAC “TRDD 7”. The VRDS is a TEAC-original CD drive mechanism that reduces rotation vibration and other unwanted vibration by clamping the CD to an aluminum turntable with the same diameter in order to maximize inertial mass.
Furthermore, instead of an ordinary DAC IC for the DAC section, which is crucial to audio quality, the VRDS-701 has a “TRDD 7” discrete DAC that incorporates our unique algorithms in a discrete circuit.
Unconstrained by conventional CD player definitions, the VRDS-701 is enhanced with future-forward functionality. The ability to play MQA CDs using full MQA decoding capabilities and support for 22.5MHz DSD and 384kHz/32-bit PCM formats as a USB DAC are some of the features that make it more than just a CD player.
- Newly Developed VRDS Mechanism
- TEAC Discrete DAC
- Fully Balanced Dual-Mono Design
- TEAC-QVCS Analog Preamp
- MQA CD Playback & Full MQA Decoding
- USB DAC: 22.5MHz DSD / 384kHz 32-Bit PCM
- 2×, 4× & 8× RDOT-NEO Upsampling
- 10MHz External Clock Input
- Dedicated Toroidal Transformers
- TEAC-HCLD2 Output Buffer
- High-Output, Low-Distortion Headphone Amp
In the box:
- VRDS-701 Fully-Balanced CD Player, Preamplifier, DAC, and Headphone Amplifier
- AC Power Cord
- Remote (RC-1338)
- (3) Foot Pad
- Manual
- Supported Media Audio CD, CD (CD-R/CD-RW * CD-DA format) (8cm CDs not supported)
- Connector: XLR x1 (L/R), RCA x1pair (L/R)
- Impedance XLR: 220Ω
- Impedance RCA: 180Ω
- Maximum Output Level (1kHz, Full scale, 10kΩ loaded) - FIXED 0dB, XLR/RCA: 2.0Vrms | FIXED +6dB, XLR/RCA: 4.0Vrms | VARIABLE, XLR: 12Vrms, RCA: 6Vrms
- Frequency Response: 5Hz - 80kHz (+1dB/ −6dB)
- S/N ratio: 105dB (A-Weight, 1kHz)
- Total harmonic distortion: 0.002% (1kHz, LPF: 20 - 20kHz)
- Input signal: DSD 11.2MHz
- Measured output: RCA
- DSD LPF: FIR1
- Headphone Amp Connector: 1/4” (6.3mm) stereo jack x1
- Maximum output: 500mW+500mW (into 32Ω)
- USB: 1 (Type-C, USB2.0 or more)
- Input signal type: Linear PCM, 44.1/48/88.2/96/176.4 /192/352.8/384kHz, 16 bit, 24 bit, 32 bit, DSD.2.8/5.6/11.2/22.5MHz
- Coaxial Connector: RCA x1
- Input level: 0.5Vp-p
- Input impedance: 75Ω
- Input signal type: Linear PCM, 32/44.1/48/88.2/96/176.4/192kHz, 16 bit/24 bit DSD2.8MHz
- Optical Connector: TOS (JEITA RC5720C) x1
- Input level: -24.0 to -14.5dBm peak
- Input signal type: Linear PCM, 32/44.1/48/88.2/96/176.4/192kHz, 16bit/24 bit, DSD2.8MHz
- Clock Sync Input Connector: BNC x1
- Input frequency: 10MHz
- Input impedance: 50Ω
- Input level
- Rectangle wave: equivalent to TTL level,
- Sine wave: 0.5 to 1.0Vrms
- Digital Outputs Coaxial: Connector: RCA x1 | Output level: 0.5Vp-p | Output impedance: 75Ω
- Optical: Connector: TOS (JEITA RC5720C) x1
- Trigger Input (12V TRIGGER IN)
- Connector: 3.5mm Mono mini jack x1
- Input Level: 12V, 1mA
- Trigger Output (12V TRIGGER OUT)
- Connector: 3.5mm Mono mini jack x1
- Input Level: 12V
- Maximum Current Supply: 100mA
- Power: AC 120V, 60Hz | AC 220-240V, 50/60Hz8
- Power Consumption: 40W
- Standby Power: 0.4W
- Overall Dimensions (W x H x D including protrusions): 17.48” x 4.38” x 13.13”
- Weight: 26.01 lbs
- Operating Temperature: 41°F to +95°F
- Operating Humidity: 5% to 85% (no condensation)
- Storage Temperature Range: −4°F to 131°F
PRODUCT INFORMATION:
Model: VRDS-701S | Barcode: 043774035731
