DESCRIPTION
The Matrix Audio MD-1 Streaming Integrated Amplifier is a powerful all-in-one Hi-Fi solution that seamlessly combines a high-resolution music streamer, precision preamplifier, and efficient power amplifier in a single chassis. Designed for simplicity without compromise, the MD-1 lets you build a complete high-end audio system using just one component and passive speakers. Employing high-efficiency digital power amplification with advanced PWM processing, the MD-1 delivers clean, dynamic power for both bookshelf and floor-standing speakers while maintaining low distortion and reduced heat. A dual femtosecond clock FPGA architecture minimizes jitter for exceptional clarity and spatial accuracy. The built-in 256-step digitally controlled analog volume system ensures precise channel balance even at low listening levels. Comprehensive connectivity includes HDMI ARC, USB Audio, multiple optical and coaxial inputs, XLR and RCA line inputs, MM phono stage, and HD Bluetooth 5.0 with LDAC and aptX HD. With Gigabit Ethernet and Wi-Fi 6, the MD-1 delivers stable, high-resolution network streaming for modern audiophile systems.
FEATURES
Dual speaker output lossless connection: Matrix Audio meticulously designs and customizes heavy-duty, gold-plated copper output binding posts, offering low transmission resistance and securely clamping speaker cables, ensuring every detail of the audio is accurately transmitted. The MD-1P also thoughtfully features dual sets of speaker binding posts, allowing simultaneous connection to two speakers. Users can quickly switch between them using the remote control, facilitating comparison listening and delivering a more convenient hi-fi experience for audiophiles.
FPGA femtosecond clock: The digital audio processing section uses a dual-femtosecond clock architecture. Two femtosecond clocks customized by Matrix provide a benchmark for sampling rates of 44.1kHz and 48kHz and their multiples. Combined with Matrix's frequency division and jitter elimination algorithms within the high-speed FPGA, they reduce clock phase jitter and reconstruct data accuracy, bringing an enhanced "airy feeling" to the music.
Precise pre-amplifier volume control: The built-in 256-level precision digitally controlled analog preamp volume system eliminates the sound quality degradation associated with mechanical wear and tear associated with traditional potentiometers. It supports fine-tuning from -80dB to +12dB with 0.5dB step accuracy . An algorithm-optimized voltage output curve ensures phase synchronization between left and right channels during volume adjustment, preserving the integrity of the sound field even at low volumes. Additionally, 12 levels of channel offset compensation facilitate fine-tuning based on speaker placement and the actual listening environment.
Preamp output & low frequency output: The MD-1P features pre-amplifier and subwoofer outputs with synchronized volume control for easy connection to power amplifiers. The subwoofer output precisely outputs low frequencies below 150Hz, conveniently connecting active subwoofers to extend the subwoofer range. The MD-1P also features dual subwoofer outputs, making it ideal for larger listening environments requiring dual subwoofers. Furthermore, a trigger port allows for power synchronization with active subwoofers, eliminating the need for manual power on/off for a more convenient experience.
Phono input: A carefully tuned low-noise RIAA curve MM phono amplifier is built in. Simply connect the output of your turntable to the phono input of this unit to quickly build a complete vinyl playback system, allowing you to easily immerse yourself in the unique musical charm of vinyl records, providing great convenience for those who are new to the vinyl experience.
Line-in: Equipped with both XLR balanced and RCA single-ended line inputs, it seamlessly connects to virtually any audio device with analog outputs. Whether you're using professional studio equipment or common home audio equipment, it's easily compatible. The inputs can also be set to direct mode, allowing it to function as a pure power amplifier. This feature greatly facilitates integration into multi-channel AV systems, meeting your needs for everything from hi-fi music to multi-channel cinema.
Comprehensive Digital Interfaces: Up to four optical and coaxial digital interfaces fully support the audio system connection needs of multiple devices in your living room entertainment environment, including set-top boxes, game consoles, and Blu-ray players. An HDMI ARC port allows for high-quality audio input from the TV, while a USB Audio port conveniently transmits computer audio, allowing music sources from your computer and TV to be perfectly displayed through the high-quality audio system.
HD BluetoothFor scenarios where HD LAN streaming isn't convenient, the MD-1 and MD-1P also offer HD Bluetooth playback. Equipped with Bluetooth 5.0 technology, they can transmit audio at up to 96kHz sampling rates and support multiple HD transmission protocols, including aptX, aptX HD, AAC, SBC, and LDAC. This ensures that the audio transmitted to your speaker system maintains exceptional sound quality, detail, and overall listening experience, allowing you to enjoy high-quality music anytime, anywhere.
Convenient Network Connection: Gigabit Ethernet is undoubtedly the best way to connect this unit, ensuring stable transmission, whether playing high-sampled PCM audio or the higher-information DSD audio. If your home is not conveniently wired and you can't run a separate Ethernet cable for the player, Wi-Fi 6 also provides a simple and convenient connection for a worry-free, high-quality audio experience.
