Panamax MR4300 Power Line Conditioner and Surge Protector
$369.00
Regular price
$504.17
Save
$135.17
(26%)
FREE SHIPPING
Free standard shipping on all orders within the continental US.
$ {{amount}}
Dedicated Support from Start to Finish
Concierge-Level Experience tailored to your needs
Assistance with Troubleshooting and Product Insights
Expert help for Product Set-Up
Free Shipping on all orders
DESCRIPTION
Nine outlet power management, specifically designed and engineered to provide protection, filtration, and power monitoring for your home theater system.
Features
9 Protected Filtered Outlets
Automatic Voltage Monitoring
Protect Or Disconnect Technology
Level 3 Linear Filtration
High Current Outlet Bank
Signal Line Surge Protection
Media Lights
Automatic Voltage Monitoring
The Nice MR Family of products offers several layers of surge protection. Patented Automatic Voltage Monitoring (AVM) technology continuously monitors the incoming power. In case of an undervoltage or brownout (too little electricity) or an overvoltage (too much electricity) a flashing red lightning bolt will be displayed and power to the equipment is automatically turned off. When voltage returns to a safe level, power to the equipment is automatically reconnected.
Protect or Disconnect™ Technology
Another critical layer of surge protection is the exclusive Nice/Panamax Protect or Disconnect™ technology. This ultra-fast protection circuitry completely protects your equipment from surges such as lightning. When overwhelmed with extreme catastrophic events, the Nice MR4300 immediately disconnects AC power to connected equipment. All Nice Power products offer this core protection technology.
Signal Line Protection
Protecting a complete system may sometimes require that signal wires coming out of the wall be protected as well. Nice has you covered there too. Universal ultra low-loss coaxial protection (as well as LAN/Ethernet) protection prevents signal lines from carrying damaging surges while maintaining full high-definition and high-speed Internet signals to your equipment for your connected life.
SPECIFICATIONS
General
Family: MR Series
Line Voltage: 120 Volts
Number of Outlets: 9
Number of Isolated Banks: 2
Outlet Descriptions: All 9 outlets are filtered and surge protected. Bank 2 outlets are high current.
Rack Mountable: Yes
Rack Ears Included: Yes
Front Panel Meter(s): LED voltmeter
Front Media Light(s): 2 rotating, dimmable media lights
Control: On/Off control to all outlets through front panel power button.
Voltage Regulation: No
Compliance: cCSAus
USB Charging: 1 front panel USB charger
Low Voltage Trigger: N/A
AC Power Cord: 8 ft. captive, with low profile plug
Dimensions (W x H x D): 17″ x 1.75″ x 6″ (2.19″ H with feet)
Weight: 6.5 lbs
AC Protection
AC Protection Technology: Protect or Disconnect; Automatic Voltage Monitoring; L-N, L-G, N-G Protection Modes; Thermal Fusing
Under-Voltage Shutoff: 100V ± 2V
Over-Voltage Shutoff: 140V ± 4V
Maximum Current Rating: 15 Amps
Initial Clamping Level: 200V Peak
Voltage Protection Rating (UL 1449 3rd Edition, 3,000A): 330V
Single Pulse Energy Dissipation: 1575 Joules
Response Time: 1ns
Nominal Discharge Current (UL 1449 3rd Edition): 3,000A
Filtration
Filtration Technology: LiFT
Filtration Rating – Bank 1: -70dB min. @ 100kHz; -65dB min. @ 250kHz; -45dB min. @ 500kHz; Max filtration: -80dB @ 150kHz
Filtration Rating – Bank 2, High Current, Low Impedance: -50dB min. @ 100kHz; -60dB min. @ 250kHz; -45dB min. @ 500kHz; Max filtration: -63dB @ 250kHz
Signal Line Protection: 1 LAN, 1 Tel, 2 Cable/Satellite
