Ortofon SPU Classic N E Moving Coil Cartridge (Black)
$1,163.99
FREE SHIPPING
Free standard shipping on all orders within the continental US.
$ {{amount}}
Dedicated Support from Start to Finish
Concierge-Level Experience tailored to your needs
Assistance with Troubleshooting and Product Insights
Expert help for Product Set-Up
Free Shipping on all orders
DESCRIPTION
The SPU Classic NE is a Moving Coil (MC) cartridge with an elliptical stylus profile that provides more detailed sound reproduction and expansive imaging. Listeners who wish to mount the SPU Classic NE on a traditional headshell may do so by using the SPU N adaptor.
Note: The SPU Classic NE is sold without the integrated headshell unit.
SPECIFICATIONS
Output voltage at 1kHz, 5cm/sec.: 0.2mV
Channel balance at 1kHz: <1dB
Channel separation at 1kHz: >20dB
Channel separation at 15kHz: >10dB
Frequency response: 20kHz - 20kHz +3/-2dB
Tracking ability at 315Hz at recommended tracking force: 65μm
Compliance, dynamic, lateral: 8μm/mN
Stylus type: Nude elliptical
Stylus tip radius: r/R 8/18μm
Tracking force range: 3.0g - 5.0g (30 - 50mN)
Tracking force, recommended: 4.0g (40mN)
Tracking angle: 20º
Internal impedance, DC resistance: 2.5 ohm
Recommended load impedance: > 10 ohm
Cartridge body material: High purity copper
Cartridge weight: 13g
DESCRIPTION
The SPU Classic NE is a Moving Coil (MC) cartridge with an elliptical stylus profile that provides more detailed sound reproduction and expansive imaging. Listeners who wish to mount the SPU Classic NE on a traditional headshell may do so by using the SPU N adaptor.
Note: The SPU Classic NE is sold without the integrated headshell unit.
SPECIFICATIONS
Output voltage at 1kHz, 5cm/sec.: 0.2mV
Channel balance at 1kHz: <1dB
Channel separation at 1kHz: >20dB
Channel separation at 15kHz: >10dB
Frequency response: 20kHz - 20kHz +3/-2dB
Tracking ability at 315Hz at recommended tracking force: 65μm
