Ortofon MC Quintet Black S Moving Coil Cartridge

  • Sale
  • $ 1,099
  • FREE SHIPPING

Free standard shipping on all orders within the continental US.



The Quintet Black S is the best example of Quintet’s overall excellence.

The Quintet Black S is graced with a Nude Shibata diamond, considered one of the best stylus profiles available, mounted on a high-performance Sapphire cantilever.

The Shibata’s slim, highly polished profile allows an exceedingly wide contact area to the walls of the groove and ensures detailed and pure reproduction throughout the spectrum, including even the most high frequency groove information.

Research and innovation Accuracy level

The MC Quintet Series is congruent with Ortofon’s unrelenting commitment to providing the most precise and accurate reproduction possible without coloration:

  • A special PC thermoplastic material is used for manufacturing of the body. This light-weight, impact resistant material is very suitable for injection-moulding and provides a very durable scratch resistant surface.
  • Neodymium magnets are implemented to achieve an optimal output.
  • Low internal impedance makes the cartridge less sensitive to load and therefore ensures compatibility with the widest range of preamps and transformers.

The MC Quintet Black S is the best of everything, true to the groove with resolution and accurate insight into each recording.

Shibata diamond Stylus

The new MC Quintet Black S model is graced with the Shibata stylus on the Sapphire cantilever.

The Quintet Black S produces a detailed and pure reproduction thoughout the spectrum, volume, and soundstage. The Quintet Black S will be unfettered by musical genre and will give the closest approach within the Quintet Series to Ortofon’s true accuracy in sound.

SPECS:
  • Channel balance at 1 kHz
    < 1.0 dB
  • Output voltage at 1 kHz, 5cm/sec
    0.3 mV
  • Channel seperation at 1 kHz
    > 23 dB
  • Channel seperation at 15 kHz
    > 15 dB
  • Frequency response 20 Hz - 20 kHz
    +/- 1.5 dB
  • Tracking ability at 315Hz at recommended tracking force
    80 μm
  • Compliance, dynamic, lateral
    15 µm/mN
  • Stylus type
    Nude Shibata on Sapphire cantilever
  • Stylus tip radius
    r/R 6/50 µm
  • Tracking force range
    2.1-2.5 g
  • Tracking force, recommended
    2.3 g
  • Tracking angle
    20°
  • Internal impedance, DC resistance
    5 Ohm
  • Recommended load impedance
    > 20 Ohm
  • Coil wire material
    Aucurum
  • Cartridge body material
    PC/Alu
  • Cartridge colour
    Black
  • Cartridge weight
    9 g

PRODUCT INFORMATION:

Model: MC Quintet Black S | Barcode: 5705796271218
