The Matrix Audio TS-1 Music Streamer is a next-generation all-in-one streamer, DAC, and headphone amplifier designed for headphone enthusiasts and active speaker systems. Built on the advanced Matrix Audio M Series streaming platform, it delivers high-end performance in a compact, minimalist form, controlled seamlessly via MA Player OS and the MA Remote App on iOS and Android. Designed as an “all-scenario audio center,” the TS-1 offers optical, coaxial, USB Audio, HDMI ARC, and RCA inputs, making it ideal for desktop audio, living room systems, vinyl playback, and TV sound. Balanced XLR and RCA outputs with selectable voltage levels simplify integration with active monitors, while a dedicated subwoofer output enables flexible 2.1-channel setups. For headphones, a fully balanced discrete headphone amplifier with 6.35mm and 4.4mm outputs delivers low noise, wide dynamics, and excellent control across IEMs and full-size headphones. Additional features include NVMe SSD storage, NAS and cloud music support, Wi-Fi 6 and Ethernet connectivity, and optional linear power supply input, making the TS-1 a refined, versatile centerpiece for modern hi-fi listening.
Matrix Audio TS-1 Music Streamer (Silver)
- $2,499.00
- FREE SHIPPING
Dedicated Support from Start to Finish
- Concierge-Level Experience tailored to your needs
- Assistance with Troubleshooting and Product Insights
- Expert help for Product Set-Up
- Free Shipping on all orders
The Matrix Audio TS-1 Music Streamer is a next-generation all-in-one streamer, DAC, and headphone amplifier designed for headphone enthusiasts and active speaker systems. Built on the advanced Matrix Audio M Series streaming platform, it delivers high-end performance in a compact, minimalist form, controlled seamlessly via MA Player OS and the MA Remote App on iOS and Android. Designed as an “all-scenario audio center,” the TS-1 offers optical, coaxial, USB Audio, HDMI ARC, and RCA inputs, making it ideal for desktop audio, living room systems, vinyl playback, and TV sound. Balanced XLR and RCA outputs with selectable voltage levels simplify integration with active monitors, while a dedicated subwoofer output enables flexible 2.1-channel setups. For headphones, a fully balanced discrete headphone amplifier with 6.35mm and 4.4mm outputs delivers low noise, wide dynamics, and excellent control across IEMs and full-size headphones. Additional features include NVMe SSD storage, NAS and cloud music support, Wi-Fi 6 and Ethernet connectivity, and optional linear power supply input, making the TS-1 a refined, versatile centerpiece for modern hi-fi listening.
- Digital Management: Simply connect an USB CD drive and use the MA Remote App, you can convert CD albums into digital audio files and save them to the device's internal storage. This process creates a digital copy of your precious CDs, seamlessly combining the high-quality audio of CDs with the flexible management of streamers. Users can enjoy the unique ritual of CD playback while transcending the limitations of physical media, turning valuable music resources into digital formats for convenient playback. Let music become a constant, beautiful companion in your life.
- Shareable Internal Storage: With the SMB protocol, computers on the same network can easily access the device's storage, making it simple to manage your music library. Additionally, the device can function as a NAS, enabling other streamers on the same network to seamlessly play the stored music.
- SD Storage Fast And Quiet: The bottom of the device features an NVMe SSD slot, allowing for the installation of an SSD to expand internal storage. A specially designed ultra-low-noise independent power supply ensures a quiet operating environment for the SSD, which surpasses what an ordinary computer can offer.
- Flexible Connection Options: If wired connection is inconvenient for you, the TS-1’s Wi-Fi 6 connectivity offers a simple and convenient solution. To ensure optimal sound quality and stable performance during high resolution audio streaming, it is recommended to give priority to use a wired connection.
- Option For Linear Power: The TS-1 is specially designed with an DC power input to unlock its full performance potential with adding a linear power supply. When both external power and AC power are connected, the system prioritizes the external power supply and disconnects the AC power, retaining only the ground connection. Additionally, the product is equipped with a power filter and multiple low-noise LDOs to power each circuit unit independently, ensuring pure and stable power delivery in every aspect.
- Digital Input
- COAXIAL & OPTICAL: PCM 16-24Bit /44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz
- DSD 2.8MHz (DoP)
- HDMI ARCPCM 16-24Bit /44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz
- USB Audio: PCM 16-24Bit /44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz, 352.8kHz, 384kHz, 705.6kHz, 768kHz
- DSD 2.8MHz, 5.6MHz, 11.2MHz (DoP)
- DSD 2.8MHz, 5.6MHz, 11.2MHz, 22.4MHz (Native)
- Aux In
- SNR: 100dB A-weighting
- THD+N < 0.004%@1k,<0.004%@20Hz-20kHz
- Frequency Response: 20Hz-20kHz ±0.1 -3dB@40kHz
- Crosstalk >-105dB
- MAX Input Level: 2.1VRMS
- Line Out
- XLR
- SNR：123dB A-weighting
- THD+N：< 0.00018%@1k, < 0.00022%@20Hz-20kHz
- Frequency Response：20Hz-20kHz ±0.1 -3dB@80kHz
- Crosstalk：>-140dB
- Output Level：4.5VRMS @ 0dB / 0~4.5VRMS Adjustable
- RCA
- SNR：120dB A-weighting
- THD+N：< 0.00020%@1k,<0.00022%@20Hz-20kHz
- Frequency Respons：20Hz-20kHz ±0.1 -3dB@80kHz
- Crosstalk：> -120dB
- Output Level：2.2VRMS @ 0dB / 0~2.2VRMS Adjustable
- SUB
- Cutoff Frequency：150Hz@-3dB
- Output Level：2.2VRMS @ 0dB / 0~2.2VRMS Adjustable
- Headphone Output
- 4.4mmBlanced
- SNR：119dB A-weighting
- THD+N：< 0.0004%@20Hz-20kHz 4VRMS
- Frequency Response：20Hz-20kHz ±0.5 -3dB@22kHz
- Output Impedance：< 2Ω
- Output Power：1000mW@33Ω, 1000mW@300Ω, 500mW@600Ω, 1%THD
- Gain：+12dB
- 6.35mmUnbalanced
- SNR：116dB A-weighting
- THD+N：< 0.0004%@20Hz-20kHz 2VRMS
- Frequency Response：20Hz-20kHz ±0.5 -3dB@22kHz
- Output Impedance：< 1Ω
- Output Power：1400mW@33Ω, 250mW@300Ω 130mW@600Ω, 1%THD
- Gain：+12dB
- Network
- LAN: 10/100/1000 MbpsWi-Fi2.4 GHz / 5 GHz
- USB: 2 x USB 3.0
- The USB port provides a maximum power of 5V/1A.
- The USB port works with devices which conform to the USB mass storage standard and supports FAT, FAT32, exFAT, and NTFS file formats, but is not guaranteed to be compatible with all storage devices.
- MA Player
- Controller appMA Remote App
- Local Playback
- Format Supported：MP3、WMA、WAV、AIF、AIFC、AIFF、AAC、FLAC、OGG、APE、ALAC、M4A、DSF、DFF、CUE、ISO
- PCM 16-24Bit/44.1kHz、48kHz、88.2kHz、96kHz、176.4kHz、192kHz、352.8kHz、384kHz、705.6kHz、768kHz
- DSD 2.82MHz, 3.07MHz, 5.64MHz, 6.14MHz, 11.29MHz, 12.29MHz, 22.58MHz, 24.58MHz
- Roon Ready
- PCM 16-24 Bit /44.1 kHz、48kHz、88.2kHz、96kHz、176.4kHz、192kHz、352.8kHz、384kHz、705.6kHz、768kHz
- DSD 2.82MHz, 5.64MHz, 11.29MHz, 22.58MHz
- QQ音乐
- The audio specs depend on the service provider
- AirPlay 2The audio specs depend on the service provider
- DLNA/UPnP The audio specs depend on the service provider
- TIDAL Connect The audio specs depend on the service provider
- Qobuz Connect The audio specs depend on the service provider
- Spotify Connect The audio specs depend on the service provider
- vTuner The audio specs depend on the service provider
- Radio ParadiseThe audio specs depend on the service provider
- Trigger
- Trigger in: DC 6-12V<10mA
- Trigger out: DC 12V/50mA MAX
- Storage Extension
- M.2 2280 2260 2242 NVMe PCIe SSD slot SSD supporting PCIe 3.0/4.0/5.0 standards，The maximum power specification provided by the expansion slot is DC 3.3V3A.
- Power
- AC input
- Wide voltage switching power supply
- Power Voltage: AC 100V-240V 50/60Hz
- Standby Power Consumption: < 5W
- MAX Power Consumption: < 35W
- DC input
- External power voltage: DC 12V ±10%
- External power wattage: Larger than 36W
- Power plug: Outer diameter 5.5mm; inner diameter 2.1mm (+ for inner, - for outer)
- Weight & size
- Weight: 2.89kg (6.37 pounds)
- Dimension
- Width: 280 mm (11.02 inches)
- Depth: 210 mm (8.27 inches)
- Height: 82 mm (3.23 inches)
- Accessories
- Power cable *1
- IR Remote *1
- Printed material *1
