DESCRIPTION
This bundle includes (1) Marantz AV 10 Reference 15.4 Channel Home Theater Pre-Amplifier/Processor and (1) Marantz AMP 20 12 Channel Reference-Level Power Amplifier
Experience uncompromising performance from the Marantz AMP 20 and AV 10—a powerful pairing engineered for discerning home theater enthusiasts. Best-in-class technologies, superior engineering, and effortless power combine for exceptional home viewing.
Marantz AMP 20 and AV 10 Home Theater System Bundle
- $12,500.00
-
Regular price
$14,000.00
Save $1,500.00 (10%)
- FREE SHIPPING
Free standard shipping on all orders within the continental US.
$ {{amount}}
Dedicated Support from Start to Finish
- Concierge-Level Experience tailored to your needs
- Assistance with Troubleshooting and Product Insights
- Expert help for Product Set-Up
- Free Shipping on all orders
DESCRIPTION
This bundle includes (1) Marantz AV 10 Reference 15.4 Channel Home Theater Pre-Amplifier/Processor and (1) Marantz AMP 20 12 Channel Reference-Level Power Amplifier
Experience uncompromising performance from the Marantz AMP 20 and AV 10—a powerful pairing engineered for discerning home theater enthusiasts. Best-in-class technologies, superior engineering, and effortless power combine for exceptional home viewing.
FEATURES
AV 10:
- Peerless Performance: Immersive spaciousness, warm and rich tone, extraordinary detail and lifelike dynamics are legendary hallmarks of Marantz sound.
- Technology Leader: AV 10 comes packed with the latest immersive audio formats, 8K video, room optimization, streaming, and more technology to simplify and elevate your enjoyment.
- Exquisite Design: A modern expression of timeless design principles, AV 10 features the iconic Marantz porthole, premium materials, and subtle sidelights that illuminate the front panel.
AMP 20:
- Ultimate Performance: AMP 20’s custom-developed Class D amplification and refined HDAM-SA2 technology create the most incredible theatrical experience possible in your home. It cleverly combines very high-power output and high channel count to create a master reference-level amplifier for ultimate home theater performance. Separate power supplies for line level and high-power stages ensure total signal purity from input to output.
- Sound Master Tuned: Our Marantz Sound Master meticulously tuned AMP 20 for amazing performance with careful parts selection to create outstanding sound in your home. Making sound the Marantz way is a seamless fusion of art and science, practiced by creators who balance and select components individually for their sonic qualities—they are the Sound Masters.
- Timeless Style: Excellence is heard and seen. AMP 20 is meticulously crafted with authentic materials in a modern style befitting its rich heritage and stunning performance. AMP 20 is elegantly constructed using steel and aluminum casework while the subtle texture molded into the front panel is lit by the dimmable soft glow of sidelights on either side of our iconic porthole design.
- Endlessly Customizable: Comprehensive connectivity options ensure AMP 20 will always deliver the perfect results to suit your home theater. Marantz has provided a rich assortment of connections and configuration options to make AMP 20 your ideal amplifier. While each of the 12 channels can operate independently, channel pairs can also be switched into bi-amp mode for isolating frequency bands from each other or switched into BTL mode to produce up to 400 watts per channel into 8 ohms for your highest output demands.
- Effortlessly Powerful: AMP 20 gives you 12 channels of commanding power in a single enclosure, each rated at 200-watt-per-channel to perform at extraordinarily high levels with no loss in fidelity. Custom Class D amplification is highly efficient, and strategically incorporated whisper-quiet fans keep the unit running optimally even under highly dynamic conditions.
- Complete Compatibility: Gold-plated RCA and high-grade XLR connectors accept audio input from most surround processors. Custom Marantz SPKT-1+ binding posts are ergonomic and provide the best possible coupling to loudspeaker cables. Low-distortion, high-power output provides ample drive to virtually any loudspeaker configuration to maximize performance.
TECHNICAL SPECS
AV10:
- Multichannel Surround: DTS HD Master / DTS:X / DTS:X Pro: Yes / Yes / Yes / DTS Neo:X / DTS Neural:X: No / Yes (15ch) / DTS Virtual:X: Yes / IMAX Enhanced: Yes / Dolby TrueHD / Dolby Atmos / Dolby Atmos Height Virtualization / Dolby Atmos Music: Yes / Yes / Yes / Yes / Dolby ProLogic Ilz / Dolby Surround: No / Yes / Auro 3D: Yes / 360 Reality Audio / MPEG H: Yes / Yes / Multichannel Stereo: Yes / Max Number of Processing (Preamp) Channels: 15.4
- Sound Enhancements: Copper Plated Chassis: Yes / Power Transformer: Toroidal / EI: Yes / No / Current Feedback Topology: Yes / Hyper Dynamic Amplifier Modules (HDAM): Yes / Pure Direct: Yes / Gold plated RCA terminals: Yes / Clock Jitter Reducer: Yes / Audyssey: MultEQ XT32 / Audyssey Dynamic EQ / Dynamic Volume: Yes / Yes / Audyssey LFC: Yes / Dirac Live upgradability: Yes / Compressed Audio Enhancer: MDAX2: Yes
- Network / HEOS Multi-room and Streaming: Yes / Bluetooth Re-transmit for Bluetooth headphones: Yes / Alexa / Google Voice Assistant / Apple HomePod: Yes / Yes / Yes / Network Audio Sharing: Yes / Lossy formats: MP3 / WMA / AAC: Yes / Yes / Yes / Lossless formats: FLAC / ALAC / WAV: Yes / Yes / Yes / Lossless formats: FLAC HD 192/24 / WAV 192/24 / ALAC 192/24: Yes / Yes / Yes / DSD Audio Streaming: Yes (2.8/5.6MHz)
- HDMI: HDMI Inputs: Back / Front: 7 / No / HDCP2.3 support: Yes / HDMI Outputs: Main / Zone: 2 / 1 / HDMI to HDMI Scaling: 1080P/4K to 8K / GUI Overlay on HDMI: Yes / HDMI 2.1: 8K/60Hz AB / 4K/120Hz AB: Yes / Yes / 8K/60Hz AB / 4K/120Hz AB Pass-through In/Out: 7 / 2 (up to 40Gbps) / HDMI 2.0: 3D / 4K / CEC / ARC: Yes / Yes / Yes / Yes / Enhanced ARC: Yes / HDR / HLG / Dolby Vision / HDR10+ / Dynamic HDR: Yes / Yes / Yes / Yes / Yes / ALLM (Auto Low Latency Mode) Pass-through for gaming: Yes / Variable Refresh Rate / Quick Frame Transport: Yes / Yes / 3D Signal Pass-Through: Yes
- Multi-Room / CI: HEOS Multi-Room Integrated: Yes / HEOS Link Compatibility: IR/ IP: Yes / Yes / Multi-Room Zones: 3 / Zone Audio Source: HDMI / Opt, Coax / Network, USB / Analog: Yes (2ch) / Yes (2ch) / Yes / Yes / Zone Audio Output: Speaker / Preout: No / Yes / Zone HDMI Output from HDMI Source: Yes / IP Control / RS232 Control / Web Control / App Control: Yes / Yes / Yes / Yes / IR Flasher In: Yes / Marantz Remote Bus: Yes / DC Trigger Output: 2 / HDMI Diagnostics: Yes
- Auto Speaker Setup by Microphone: Audyssey MultEQ XT32
- Dirac Live: (upgrade)
- Front Display: 2 line FLD + port hole OLED
- Graphic User Interface - GUI: Modern HD GUI
- GUI Languages: 3
- Inputs/Outputs: Composite In / Out: No / No / Component In / Out: No / No / HDMI In / Out: 7 / 3 / Multi-Room Video Out: Video / HDMI: No / Yes / Analogue In / Out: 5 (1x XLR) / No / Phono (MM): In Yes / Digital In: Optical / Coaxial: 2 / 2 / Multi-Room Out: analog / digital: 2 / No / Multichannel Pre Out: Yes (17.4 RCA & 17.4 XLR) / Subwoofer Out: 4 (independent) / Speaker A / B: assignable pre out / Bi-amp drive: assignable pre out / Multi-Room Speaker Terminal: pre out
- System Remote Control RC047SR
- Pre-Programmed / Learnable / LCD Display Yes / Yes / Yes
- Power Consumption in W 100
- Standby Consumption in W 0.2
- CEC Standby Consumption in W 0.5
- Network Standby Consumption in W Less than 2.0
- Maximum Dimensions: 17.4 x 19.8 x 7.4
- Weight in lbs.: 37.0
AMP 20:
- Main Amplifier In: Balanced & Unbalanced: 12ch (Exclusive use by a selector switch.)
- Speaker Terminal: SPKT-1+
- Number of Speaker Terminals: 12
- Bi-Amp Drive / BTL Drive: Yes / Yes
- Level Meter: Yes
- Chassis: Copper Plated
- RS232 Control: Yes
- IR Flasher In: Yes
- Marantz Remote Bus: Yes
- DC Trigger Input / Output: 1 / 1
- Number of Power Amps: 12
- Power Output (8 ohm, 1 kHz, 0.05% 2ch Drive) Normal / BTL: 200W / 400W
- Power Output (4 ohm, 1 kHz, 0.7% 2ch Drive) Normal: 400W
- Power Output (8 ohm, 1 kHz, 0.7% 5ch Drive) Normal: 200W
- Front Display: Level Meter
- Auto Power Off: Yes
- Metal Front Panel: Yes
- Power Consumption: 400W
- Power Consumption, No-Sound: 110W
- Standby Consumption: 0.2W
- Maximum Dimensions (W × D × H): 17.4 × 17.4 × 7.5 in.
- Weight: 39.7 lbs
- Limited Warranty (United States and Canada): 5-year
PRODUCT INFORMATION:
Model: AMP20+AV10 | Barcode: 789232964068
