The 805 D4 stand-mount loudspeaker is the most compact model in the 800 Series Diamond range, but it's still packed with advanced technologies, including the Diamond dome tweeter and the Solid Body Tweeter-on-Top. * Stand(s) not included.
Little Diamond
Solid Body Tweeter assembly
Our newest Solid Body Tweeter-on-Top housing features an elongated form with a longer tube-loading system, producing an even more free and open sound with high frequencies. The carefully decoupled housing is milled from a single solid block of aluminum to better resist resonance.
Rear-mounted crossover
The new reverse-wrap orientation of the cabinet on 805 D4 means we can place its sensitive crossover components inside their own, dedicated space within the cabinet, which has critical benefits to both performance and serviceability. We’ve taken the opportunity to upgrade the speaker terminals, too.
SPECS:
Technical features:
-
Diamond tweeter
-
Solid body Tweeter-on-Top
-
Continuum™ cone bass/mid
-
Matrix™
-
Anti-Resonance plug
-
Flowport
Description:
-
2-way vented-box system
Drive units:
-
1x ø25mm (1in) Diamond dome high-frequency
-
1x ø165mm (6.5in) Continuum cone bass midrange
Frequency range:
-
34Hz to 35kHz
Frequency response:
-
42Hz to 28kHz (+/-3dB from reference axis)
Sensitivity:
-
88dB (on axis at 2.83Vrms at 1m)
Harmonic distortion:
-
2nd and 3rd harmonics (90dB, 1m on axis)
-
<1% 90Hz – 20kHz
-
<0.3% 120Hz – 20kHz
Nominal impedance:
-
8Ω (minimum 4.6Ω)
Recommended amplifier power:
-
50W – 120W into 8Ω on unclipped programme
Max recommended cable impedance:
-
0.1Ω
Net weight:
-
15.55kg (34.3 lb)
Dimensions:
-
Height: 440mm (17.3 in)
-
Width: 240mm (9.4 in)
-
Depth: 373mm (14.7 in)
