The 801 D4 Signature is an optimized version of B&W's most advanced loudspeaker. It features meticulously evolved technology, carefully crafted design and unique finishes that culminate in the pinnacle of performance. This is Bowers & Wilkins 800 Series Signature flagship loudspeaker.
Optimized for perfection
Diamond Dome tweeter
One of our most significant accomplishments over the past two decades, the ultra-stiff, supremely accurate Diamond Dome tweeter is the perfect combination of low mass, exceptional stiffness, and outstanding accuracy. Fifteen years after we introduced it, we haven't found a better tweeter dome technology.
Solid Body Tweeter
Our Solid Body Tweeter-on-Top housing features an elongated form with a longer tube-loading system and an all-new design of tweeter grille, producing an even more free and open sound with high frequencies.
Upgraded crossover
Our 801 D4 Signature uses upgraded rear-mounted crossover designs mounted on stiff aluminum spines. This isolates the sensitive capacitors from the unwanted effects of air pressure within the enclosure and makes for a very effective heatsink to ensure optimum performance when in use.
Aluminum top-plate
Every new 800 Series Signature model has a significantly upgraded cabinet design with an all-new, optimized aluminum top section for even greater stiffness. The same design also provides a perfect mounting point for Leather by Connolly cabinet detailing, with luxurious full-grain blue leather for our Midnight Blue Metallic models and full-grain black leather for our California Burl Gloss models.
SPECS:
Technical features:
-
Diamond tweeter
-
Solid Body Tweeter-on-Top
-
Continuum™ cone FST™ midrange
-
Anti-Resonance plug
-
Biomimetic Suspension
-
Turbine Head
-
Matrix™
-
Aerofoil™ Profile bass cones
-
Flowport™"
Description:
-
3-way vented-box system
Drive units:
-
1x ø25mm (1in) Diamond Dome high-frequency
-
1x ø150mm (6in) Continuum™ cone FST™ midrange
-
2x ø250mm (10in) Aerofoil™ Profile bass
Frequency range:
-
-6dB 13Hz - 35kHz
Harmonic distortion:
-
2nd and 3rd harmonics (90dB, 1m on axis)
-
<1% 30Hz – 20kHz
-
<0.3% 100Hz – 20kHz
Nominal impedance:
-
8Ω (minimum 3.0Ω)
Recommended amplifier power:
-
50W - 1,000W into 8Ω on unclipped programme
Max recommended cable impedance:
-
0.1Ω
Frequency response:
-
15Hz - 28kHz ±3dB
Sensitivity:
-
90dB spl (2.83Vrms, 1m)
Dimensions:
-
Height: 1221mm (48.1in)
-
Width: 451mm (17.8 in)
-
Depth: 600mm (23.6 in)
Net weight:
-
100.60kg (221.8 lb)
PRODUCT INFORMATION:
Model: FP44229 | Barcode: 714346341085
