DESCRIPTION
The AT-LP3XBT turntable combines 60 years of high-fidelity design with convenient Bluetooth® technology, giving you all the benefits of vinyl with the freedom to connect to the latest Bluetooth® speakers or headphones.
The successor model of the previous AT-LP3 comes with beneficial upgrades, such as wireless compatibility with the high-quality Qualcomm® aptX Adaptive audio and Qualcomm® aptX™ audio codecs, the AT-VM95C cartridge, which is compatible with any of Audio-Technica‘s VM95 Series replacement styli, detachable RCA output cables, and the external AC adapter, which handles the AC/DC conversion outside of the chassis, reducing noise in the signal chain.
Features
Fully automatic belt-drive turntable operation with two speeds: 33-1/3, 45 RPM
High-fidelity audio with Bluetooth wireless technology
Connects wirelessly to speakers and other devices equipped with Bluetooth wireless technology or to wired audio systems and powered speakers via included dual RCA output cable
Compatible with the high-quality Qualcomm® aptX Adaptive audio and Qualcomm® aptX™ audio codecs
Balanced straight tonearm with hydraulically damped lift control and rest
AT-VM95C cartridge is compatible with any VM95 Series replacement stylus, offering a wide choice of options for every budget and application
Includes the AT-HS3 universal headshell
Built-in switchable phono/line pre-amplifier with detachable dual RCA output cable with grounding wire
Anti-resonance, die-cast aluminum platter with felt mat
Damped base construction for reduced low-frequency feedback coloration
External AC adapter handles AC/DC conversion outside of the chassis, reducing noise in the signal chain
SPECIFICATIONS
Communication Specifications
Communication System: Bluetooth version 5.2
RF Output: 2.5 mW EIRP
Maximum Communication Range: Line of sight - approx. 10 m (33')
Applicable Cartridge Weight Range (including headshell): 14.5 to 20 g
Cartridge and Headshell Specifications
Cartridge Model: AT-VM95C
Cartridge Type: VM
Recommended Load Impedance: 47,000 ohms
Output Voltage: 4.0 mV (1kHz, 5cm/sec)
Stylus: 0.6 mil bonded conical
Cantilever: Aluminum pipe
Tracking Force Range: 1.8 to 2.2 g (standard 2.0 g)
Cartridge Weight: 6.1g (0.22 oz)
Headshell Model: AT-HS3BK
Headshell Weight
11.1 g (including lead wires)
10.3 g (excluding lead wires)
Headshell Overhang Adjustment: ±8 mm
General Specifications
Power Supply Requirements: 100-240 V, 50Hz/60Hz, 0.6 A Max.
Power Consumption: 2 W
AC Adapter: 12 V, 0.5 A
Dimensions (W x H x D): 17" × 5” x 15"
Weight: 11 lbs
Replacement Stylus (sold separately): AT-VMN95C
Replacement Headshell (sold separately): AT-HS3BK
Replacement Belt (sold separately): AT-LP3XBT exclusive belt
