Rotel RAP-1580 MKII Amplified Surround Processor (Black)

DESCRIPTION

The RAP-1580MKII is the ideal home theater solution delivering uncompromised audio and video performance supporting 7.1.4 Dolby Atmos and DTS:X processing with 7 channels of 140 Watts of Class AB output power into 4 ohm loads and licensed for Dirac Live room correction technology ensuring optimal performance in any setting.

DISCONTINUED

Rotel RAP-1580 MKII Amplified Surround Processor (Black)

Unfortunately, this product has been discontinued. Please contact us at 1.844.GRAMOPHONE for further assistance

Free standard shipping on all orders within the continental US.

Dedicated Support from Start to Finish

Concierge-Level Experience tailored to your needs
Assistance with Troubleshooting and Product Insights
Expert help for Product Set-Up
Free Shipping on all orders

DESCRIPTION

FEATURES

INTERMODULATION DISTORTION (60Hz:7kHz, 4:1): <0.05%
DAMPING FACTOR (1kHz, 8 ohms): 230
TOTAL HARMONIC DISTORTION (THD):<0.05%
Dolby® Surround: Yes
Dolby® TrueHD: Yes
Dolby® Atmos: Yes
DTS-HD Master Audio: Yes
DTS:X: Yes
Dirac Live LE: Yes

TECHNICAL SPECS

POWER REQUIREMENTS: 120V, 60Hz
POWER CONSUMPTION: 1100W
STANDBY POWER CONSUMPTION: 0.5W
VIDEO INPUT RESOLUTIONS: 480i/576i, 480p/576p, 720p, 1080i, 1080p, 1080p 24Hz, 3D, 4K, UHD
VIDEO OUTPUT RESOLUTION: 480i/576i, 480p/576p, 720p, 1080i, 1080p, 1080p 24Hz, 3D, 4K, UHD
HDMI INPUTS/OUTPUTS: 8 inputs with 3 supporting HDCP 2.2, 2 outputs supporting HDCP 2.2, Audio Return Channel
Line Level Inputs (RCA): 300mV
Line Level Inputs (XLR): 600mV
Phono Input (MM): 3.85mV
Line Level Inputs (RCA): 100kΩ
Line Level Inputs (XLR): 100kΩ
Phono Input (MM): 47kΩ
DIMENSIONS (W × H × D): 17" × 7.55" × 18.5" (431 × 192 × 470mm)
NET WEIGHT: 50.27lbs (22.8kg)

PRODUCT INFORMATION:

Model: ROT1050007 | Barcode: 672563259111
