DESCRIPTION

This bundle includes: (1) Marantz MODEL 10 Reference Integrated Amplifier, (1) Marantz SACD 10 Reference SACD Player, and (1) Marantz LINK 10n Reference Network Audio Player

Experience the ultimate in high-end audio with this Marantz reference-series bundle. The MODEL 10 Integrated Amplifier delivers uncompromising power and precision, the SACD 10 Player provides flawless SACD/CD and high-resolution playback, and the LINK 10n Network Audio Player brings advanced streaming and DAC performance. Together, they form a complete reference-grade system designed for discerning audiophiles who demand the finest sound quality.

Marantz MODEL 10/SACD10/LINK10n Bundle

$40,000.00
Regular price $43,000.00
Save $3,000.00 (6%)
FREE SHIPPING

Free standard shipping on all orders within the continental US.

CONTACT YOUR NEAREST SHOWROOM

FOR CONCIERGE EXPERIENCE

Timonium - 410.308.1650

Columbia - 410.381.2100

Gaithersburg - 301.296.6202

Dedicated Support from Start to Finish

Concierge-Level Experience tailored to your needs
Assistance with Troubleshooting and Product Insights
Expert help for Product Set-Up
Free Shipping on all orders

DESCRIPTION

This bundle includes: (1) Marantz MODEL 10 Reference Integrated Amplifier, (1) Marantz SACD 10 Reference SACD Player, and (1) Marantz LINK 10n Reference Network Audio Player

FEATURES

MODEL 10:

2 Channels
250 Watts per Channel
All-New Marantz SMPS
Fully balanced dual mono amplifiers
Phono MM/MC
Copper-plated chassis

LINK10n:

Hi-Res audio support up to DSD 11.2 MHz and PCM 384 kHz / 32 bit
2.1 channel subwoofer output
HDMI ARC with CEC support for superior TV and gaming sound
High-resolution and full-color HD OLED Display
HEOS® Built-in including high-resolution streaming and other technologies
Machined aluminum construction and triple layered copper-plated design.
Analog out XLR and RCA gold-plated terminals (fixed and variable)
Digital inputs: coaxial, optical, USB-A, USB-B, DAC, HDMI-ARC
Analog inputs: Aux in x1, MM/MC Phono with switchable impedance
Newest HDAM and MM circuits and eight-layer PCBs

SACD 10:

Marantz designed SACDM-3 disc transport
DSD 256 and PCM 384 / 32 support via USB
Marantz Musical Mastering Stream and Conversion circuit evolution
Fully discrete variable gain headphone amplifier
Dual power supplies with toroidal transformers
OLED display
Marantz Industrial Design
8 Layer PCB provides optimum circuit layout
Digital in: Optical, Coaxial, USB-A, USB-B DAC
Analog out XLR & RCA – fixed level / Digital out: coaxial, optical

TECHNICAL SPECS

MODEL 10:

Rated Output Power
250W + 250W (8ohm,20Hz-20kHz,THD 0.05 %)
500W + 500W (4ohm,20Hz-20kHz,THD 0.05 %)
Unit Dimensions (W × H × D): 17.32” × 7.56” × 18.62”
Net weight: 74.29 lbs.
Speaker Impedance: 4~16ohm
Frequency Response: 5Hz~60kHz +0dB/-3dB / 20Hz~20kHz +0dB/-0.3dB
Total Harmonic distortion: 0.005% (125W, 8ohm, 20-20kHz) (CCIF IMD, DFD IMD)
Damping Factor: 500 (8ohm, 20Hz-20kHz)
Input Sensitivity: Phono input
MM: 3.6 mV / 36 kohm
MC (Low): 400 µV / 33 ohm
MC (Mid): 400 µV / 100 ohm
MC (High): 400 µV / 390 ohm
RIAA Deviation: 20 Hz - 20 kHz ±0.5 dB (MM/MC)
Phono Maximum Input: MM : 80mV / MC : 8mV
Input Sensitivity: CD/LINE/RECORDER
350 mV/41kohm (Unbalanced)
700 mV/36kohm
Input Sensitivity: Power Amp input
Unbalanced: 1.58V / 41kohm (Gain : 29dB)
Balanced: 3.16V / 15kohm (Gain : 24dB)
SN Ratio: PHONO (MM): 88dB / PHONO (MC): 76dB / CD: 122dB / Balanced: 122dB
BASS : 50Hz ±10dB
TREBLE : 15kHz ±10dB
Power Consumption: 270W (0.1W at Standby)
Power Amplifier Circuit: Switch Mode BTL
Power Trans: Toroidal transformer in shielding case for preamplifier section only
SMPS for Power amplifier: L/R independent
Pre Amplifier Circuit New HDAM High Grade, Full balance
Volume: Electric / Variable gain
Bass / Treble / Mid / Balance Control: Yes / Yes / No / Yes
Type of Tone Control: Electric
Headphone Circuit: HDAM-SA2+ Diamond buffer
Source Direct: Yes
Power amp mode turn off Pre-Amp power supply: Yes
Mono mode: Yes, Switch Stereo / Bi-Amp on Rear Panel
Phono Input: Yes (MM / MC)
Marantz Musical Premium Phono EQ w/ Selectable MC impedance (3 position)
PHONO (MC Low): 400 µV / 33O
PHONO (MC Mid): 400 µV / 100O
PHONO (MC High): 400 µV / 390O
PHONO (MM): 3.6 mV / 39kO
Analog Input (include Phono) / REC Out (RCA): 4 /1
Balanced XLR input: 2
Power Amp Direct Yes [RCA (Thick nickel plated independent terminals)/ XLR]
Pre out Yes [RCA (Thick nickel plated independent terminals)/ XLR]
2 sets of Speaker Output: Yes (Bi-wiring)
Speaker Terminal: Marantz Original SPKT-100+, 2 (High quality and high-purity copper plated)
Headphone Output: 1
Remote Control Bus Terminal: Yes (RC-5 In / Out)
Remote Internal / External Switch: Yes
Flasher Input: Yes
AC Inlet: Yes
Other: F.C.B.S. (Floating Control Bus System)

LINK10n:

Unit (W × H × D): 17.32” × 7.55” × 16.61" (with antenna)
Net weight: 73.41 lbs.
Voice Assistants: Apple Siri, Google Assistant
Frequency Response: PCM 2Hz–50kHz (-3dB)
Harmonic distortion: PCM 0.0004%
S/N: PCM 0.0004%
Dynamic range: PCM 0.0004%
Line Output Level
UNBALANCED: 2.0Vrms
BALANCED: 4.0Vrms
Headphone Output Level: 130mW / 32 ohms
Frequency Response (analog input): 5 Hz–100 kHz (+0dB/-3 dB)
Harmonic distortion (analog input): 0.001% (20Hz–20kHz)
S/N
PHONO (MC): 76dB
PHONO (MM): 88dB
BALANCED: 122dB
LINE: 122dB
Phono Input sensitivity
MM: 8mV
MC: 80mV
Phono Input impedance
MC Low: 32 ohms
MC Mid: 100 ohms
MC High: 390 ohms
MM: 39 kohms
Power Consumption: 75W
Standby: Less than 0.3W
Network Control On (Bluetooth, Ethernet, Wi-Fi, USB): Less than 2W
Output Circuit: New HDAM
Power Transformer: Toroidal
Pre Amplifier Circuit: New HDAM High Grade, Full balance
Volume: Electric (MUSES 72323) Variable gain
Bass / Treble / Mid / Balance Control: Yes / Yes / No / Yes
Type of Tone Control: Electric
Headphone Circuit: Discrete
H/P Amp Gain Setting: Yes (Low / Mid / High)
H/P On.Off Setting: H/P Off automatically, when in use
DAC Circuit: New MMM-Conversion
Dither: MMM-Stream (Dither 1, 2, Off)
Noise Shaper: MMM-Stream (Balanced, Natural, Dynamic Music, Dymanic Voice)
Digital Filter: MMM-Stream (Filter 1, 2 Selectable)
Jitter Reducer: Yes
DAC Master Clock Design (No Support for Network Playback): Yes
Asynchronous mode (for USB-B input): Yes
Isolator (for USB-B input): Yes (Complete Isolation System Duo)
Fixed Analog Output (RCA): Cinch × 1 (Thick nickel-plated independent terminals)
Pre / Variable Audio Output (RCA): Cinch × 1 (Thick nickel-plated independent terminals)
Fixed Balanced XLR Output: Yes (1 Pair)
Pre/ Variable Balanced XLR Output: Yes (1 Pair)
RCA Input: Cinch × 1 (Thick nickel plated independent terminals
Balanced XLR Input: Yes (1 Pair)
Phono input
Yes (MM / MC)
Marantz Musical Premium Phono EQ w/ Selectable MC impedance (3 position)
Optical input / output (Maximum Support) 2 / 1 (on/off switchable): 44.1 kHz - 192 kHz
Coaxial input / output (Maximum Support) 1 / 1 (on/off switchable): 44.1 kHz - 192 kHz
HDMI input / output: No / Yes (ARC)
Headphone Output: Yes (F6.3 ×1)
Subwoofer: Yes with LP filter adjustable

SACD 10:

Unit (W × H × D mm) 440 × 192 × 442
Cabinet Size 440 × 192 × 422
Net weight 33.0 kg
Frequency Response
SACD: 2Hz–50kHz (-3dB)
CD: 2Hz–20kHz (±1.0dB)
Harmonic distortion
SACD: 0.0004%
CD: 0.0015%
S/N
SACD: 118dB
CD: 116dB
Dynamic range
SACD: 112dB
CD: 98dB
UNBALANCED: 2.0Vrms
BALANCED: 4.0Vrms
Headphone Output Level: 130mW / 32 ohms
Power Consumption: 55W
At Standy: Less than 0.3W
Output Circuit: New HDAM
Power Transformer: Toroidal
Headphone Circuit: Discrete
H/P Amp Gain Setting: Yes (Low / Mid / High)
H/P On.Off Setting: H/P Off automatically, when in use
DAC Circuit: New MMM-Conversion
Dither: MMM-Stream (Dither 1, 2, Off)
Noise Shaper: MMM-Stream (Balanced, Natural, Dynamic Music, Dymanic Voice)
Digital Filter: MMM-Stream (Filter 1, 2 Selectable)
Jitter Reducer: Yes
DAC Master Clock Design (No Support for Network Playback): Yes
Asynchronous mode (for USB-B input): Yes
Isolator (for USB-B input): Yes (Complete Isolation System Duo)
Fixed Analog Output (RCA): Cinch × 1 (Thick nickel plated Maching copper L/R independent terminals)
Fixed Balanced XLR Output: 1
Optical input / output (Maximum Support): 2/1 (44.1 kHz - 192 kHz)
Coaxial input / output (Maximum Support) 2/1 (44.1 kHz - 192 kHz)
Headphone Output: Yes (f6.3 x 1)
Remote Control Bus Terminal: Yes
Remote Internal / External Switch: Yes

PRODUCT INFORMATION:

Model: MODEL10/LINK10N/SACD10/U1B | Barcode: 880263738236
