The Luxsin X9 Desktop DAC & Headphone Amplifier is a flagship-grade audio solution engineered for audiophiles who demand precision, power, and customization. Featuring the premium AK4499EX DAC and a fully balanced signal path, the X9 delivers ultra-low distortion (THD+N -120dB), exceptional clarity, and expansive dynamic range. Its advanced R2R volume control ensures precise 0.1dB channel matching for accurate, distortion-free playback.
Luxsin’s proprietary HP-EQ technology provides real-time headphone calibration, aligning sound with the Harman curve or custom profiles from a growing database of over 2,500 models. Intelligent impedance detection automatically optimizes gain settings, while dynamic negative feedback circuitry enhances tonal purity and detail retrieval.
With features like digital crossfeed, adjustable soundstage, and a vibrant 4.0-inch touchscreen with customizable VU meters, the X9 delivers both visual and sonic immersion. Its CNC-machined aluminum chassis, versatile connectivity, and preamp functionality make it a powerful, all-in-one desktop audio hub for high-resolution listening.
Luxsin X9 Desktop DAC & Headphone Amplifier (Silver)
mon0000025873
B0G43B5NGQ
- $1,099.00
- FREE SHIPPING
Dedicated Support from Start to Finish
- Concierge-Level Experience tailored to your needs
- Assistance with Troubleshooting and Product Insights
- Expert help for Product Set-Up
- Free Shipping on all orders
The Luxsin X9 Desktop DAC & Headphone Amplifier is a flagship-grade audio solution engineered for audiophiles who demand precision, power, and customization. Featuring the premium AK4499EX DAC and a fully balanced signal path, the X9 delivers ultra-low distortion (THD+N -120dB), exceptional clarity, and expansive dynamic range. Its advanced R2R volume control ensures precise 0.1dB channel matching for accurate, distortion-free playback.
Luxsin’s proprietary HP-EQ technology provides real-time headphone calibration, aligning sound with the Harman curve or custom profiles from a growing database of over 2,500 models. Intelligent impedance detection automatically optimizes gain settings, while dynamic negative feedback circuitry enhances tonal purity and detail retrieval.
With features like digital crossfeed, adjustable soundstage, and a vibrant 4.0-inch touchscreen with customizable VU meters, the X9 delivers both visual and sonic immersion. Its CNC-machined aluminum chassis, versatile connectivity, and preamp functionality make it a powerful, all-in-one desktop audio hub for high-resolution listening.
- AK4499EX DAC + OPA1612 op-amp delivers ultra-low distortion
- Advanced HP-EQ tuning
- Digital crossfeed for fatigue-free, speaker-like imaging
- Fully balanced R2R volume circuit ensures impeccable channel matching
- Elegant 4-inch touchscreen with blackout mode and auto-standby
- Play & DAC: support DSD512，PCM 768KHz 32-bit
- Bluetooth audio input: BT5.0 support AAC/SBC
- USB-B audio input: support Windows (10, 11)，Android，IOS。support DSD512，PCM 768KHz 32-bit
- Optical/Coaxial audio input: support PCM 192KHz 24-bit，DoP64
- HDMI ARC: support PCM 192KHz 24-bit
- Analog input: RCA（unbalance），max gain +10dB
- Analog audio output interface: XLR (balanced)+RCA (unbalanced)+subwoofer output
- XLR Audio Output: output level 4.2Vrms@0dBFS
- Frequency Response：20Hz~20KHz (±0.25dB)
- Dynamic Range：> 128dB
- Signal-to-Noise Ratio (SNR)：>128dB
- THD+N：<0.000096% (-120.3dB) @ Unweighted
- Crosstalk：>-117dB
- RCA Audio Output level 2.1Vrms@0dBFS
- Frequency Response：20Hz~20KHz (±0.25dB)
- Dynamic Range：> 125dB
- Signal-to-Noise Ratio (SNR)：>125dB
- THD+N：<0.00010% (-119dB) @ Unweighted
- Crosstalk：>-114dB
- Headphone Audio output level 4-15Vrms@0dBFS
- Frequency Response：20Hz~20KHz (±0.25dB)
- Dynamic Range：> 128dB
- Signal-to-Noise Ratio (SNR)：>128dB
- THD+N：<0.00016% (-116dB) @ Unweighted
- Display: 4-inch TFT Fully Laminated Touchscreen（960X400）
- Hardware solution: DAC：AK4191EQ+AK4499EX ；Bluetooth decoding：QCC5125
- Audio processor: AKM 7739 DSP
- Op-Amp chip: OPA1612
- dimension: Width: 11.81x8.11x2.55"
- Power supply: Ultra-Low Noise Linear Power Supply
- Rated Power: 25W
- Packing list: Power Cable ×1, Remote Controller ×1, USB-B Cable×1, User Manual ×1
- Color: Silver
- Weight: 8.20lbs
- Operation method: Touchscreen, Infrared + Bluetooth Remote Control, Luxsin App (compatible with Android and iOS)
- Input: USB-A Port For Firmware Updates Only, USB- B Port
- USB Audio System Compatibility: Windows (10, 11), Android, iOS; Supports up to Stereo DSD512, PCM 768kHz/32-Bit
- USB Type-C: USB Audio System Compatibility: Windows (10, 11), Android, iOS; Supports up to Stereo DSD512, PCM 768kHz/32-Bit
- Analog (unbalanced input): RAC*2（unbalanced），Max Gain +10dB
- Optical: Support up to PCM 192KHz 24-bit，DoP64
- Coaxial: RAC*1
- Bluetoth input: BT5.0，support AAC/SBC
- HDMI ARC: support PCM 192KHz 24-bit
- TRIGGER Connection: 3.5mm Headphone Jack (TRIGGER IN ×1 + TRIGGER OUT ×1)
- WiFi: WiFi 2.4G / 5G
- Volume Knob: Encoder Knob
- Power Button: Single Press: Mute, Long Press: Standby
- Power Switch: Rocker Switch
- Power Supply: AC 100-240V~50/60Hz
- Controller: 12-Button Infrared Remote Control
- Balanced Circuit Output: XLR3 Balanced Socket
- Unbalanced Circuit Output: RCA*2
- Subwoofer Output: RCA*2
- Balanced Headphone Output: 4.4mm Socket ×1 + XLR4 Balanced Socket ×1
- Unbalalced Headphone Output: 6.35mm Socket
PRODUCT INFORMATION:
Model: | Barcode: 6977843850007
