Denon PMA-1700NE Integrated Amplifier

  • Sale
  • $ 2,099
  • FREE SHIPPING

Free standard shipping on all orders within the continental US.



Featuring advanced ultra-high current single push-pull circuit power, Advanced AL32 Processing, and MM/MC phono equalizer, the Denon PMA-1700NE integrated amplifier delivers extraordinary sound quality with precise detail.

Drive your loudspeakers with 140 Watts of power- per-channel into 4 Ohms. This integrated amplifier offers compatibility with the widest range of 6 speaker types and impedances for operational stability.

Advanced AL32 Processing Plus supports high-resolution 384 kHz/32-bit audio sources. The algorithms restore information that was lost during the digital recording to ensure detailed playback.

FEATURES

  • Advanced AL32 Processing Plus
  • USB-DAC
  • High-precision electrical controls
  • MM and MC phono equalizer
  • Optical and coaxial digital inputs
  • External pre-amp input terminals
  • TV auto standby (digital input)
  • Six-block chassis configuration and direct mechanical ground construction
  • Digital isolator
  • Analog mode

TECHNICAL SPECS

  • Rated Output Power
    • 70W + 70W (8ohm,20Hz-20kHz,THD0.07%)
    • 140W + 140W (4ohm, 1kHz, THD0.7%)
  • Speaker Impedance
    • A or B : 4 ~ 16ohm
    • A + B : 8 ~ 16ohm
  • Frequency Response: 5Hz - 100kHz (0~ -3dB)
  • Total Harmonic Distortion 0.01 % (Rated output: –3 dB), 8 ohm/ohms, 1 kHz
  • Dumping Factor: 100 and over
  • Input Sensitivity: Phono input
    • MM: 2.5 mV / 47 kohm
    • MC: 200
  • Signal to Noise Ratio
    • PHONO (MM): (89dB)
    • PHONO (MC): (74dB)
    • CD: (107dB)
  • Power Amplifier Circuit: New UHC-MOS, Single Push Pull
  • Bass / Treble / Mid / Balance Control: Yes / Yes / No / Yes
  • Source Direct: Yes
  • Analog Amp Mode: Yes (button on front panel)
  • DAC Circuit: PCM1795
  • Digital Filter: Fixed
  • Digital Processing: Advanced AL32 Processing Plus
  • DAC Master Clock Design (Doesn’t Support Network Playback): Yes
  • Asyncronous mode (for USB-B input): yes
  • Analog Input (include Phono) / REC Out (RCA): 4/1 (PHONO/ CD/ AUX/ RECORDER)
  • Optical input / output (Maximum Support): 2 / 0 (192kHz/24bit)
  • Coaxial input / output (Maximum Support): 1 / 0 (192kHz/24bit)
  • Ext. Pre Input (Power Amp Direct): Yes(Ext.Pre)
  • 2 sets of Speaker Output: Yes (Bi-wiring)
  • Speaker Terminal: Gold Plated
  • AC Inlet: Yes
  • Wi-Fi: No
  • HEOS: No
  • Unit (W x D x H) 434 x 410 x 135mm, 17.1 x 16.1 x 5.3in
  • Net weight 17.6kg, 38.8lb
  • Packaging Dimensions (W x D x H) 548 x 520 x 249mm, 21.6 x 20.5 x 9.8in
  • Packaging gross weight 20.4kg, 45lb
